Specification:
|
|
|
System
|
|
|
Construction
|
Front Aluminum Bazel and steel enclosure |
|
Disk Driver Bay |
2 x 3.5” HDD capacity |
|
Cooling Fan |
2 x 8025 low-noisy swap cooling fan, with air filter and Moistureproof design |
|
Keyboard |
Built-in 88-keys keyboard and touch pad. |
|
OSD |
OSD function in front panel |
|
I/O Connector |
Front panel: 2xUSB2.0Rear panel: 1xVGA, 2xPS/2(Optional) |
|
LED indicators & Switch |
Power LED indicator(Green), HDD LED indicator(Red), ATX Power Switch |
|
Color |
Black |
|
LCD Panel |
|
|
Display type |
8" XGA TFT LCD |
|
Resolution |
800 X 600 |
|
Luminance |
250 cd/m2 |
|
Contrast Ratio |
500:1 |
|
Max Colors |
16.2MB |
|
Backlight |
LED |
|
Pixel Size |
0.297 x 0.297 |
|
View angle |
150°(H) , 135°(V) |
|
Response time |
8 ms |
|
LCD MBTF |
50,000hrs |
|
Touchscreen (optional)
|
|
|
Type |
Resistive Touchscreen |
|
Resolution |
4096x4096 |
|
Controller Interface |
Internal USB ( RS-232 interface option) |
|
Light Transmission |
81% or more |
|
Operating Force |
≤250g |
|
Life Expectancy |
10 Millions |
|
Environmental Specifications
|
|
|
Operate tempreture |
32 °F~125 °F (0 °C to 50°C) |
|
Storage temperature |
-4 °F~140 °F (-20 °C to 60 °C) |
|
Storage Humidity |
5% to 95%@ 40°C , non-condensing |
|
Vibration |
5-17Hz/1mm amplitude, 17-640Hz/1.5g acceleration |
|
Shock |
1G /peak(11 msec. duration) |
|
Safty |
FCC/VDE(Level A) |
|
Packing info |
|
|
Dimensions(WxHxD) |
482.6 x 179 x 451.5mm |
|
Weight |
Net:21 KG, Gross: 25KG |
|
Exporting packing |
Screws x1 bag, VGA cable x1, User manual x1,Warranty card x1, Certificatex1, PS/2 cable x2, Shock pad x2, Packing list x1 |
|
Ordering information
|
|
IWPC-408-AX
IWPC-408-ATX |
8"TFT LCD, AT rear panel, with Industrial power supply
8"TFT LCD, ATX rear panel, ATX MB foam factor or Industrial Moterboard(Optional) |
